| PROCESSOR | CPU | Intel® Core™ 5th Broadwell-U Soc i3/i5/i7 CPU Integrated Intel® Broadwell i7-5500U dual cores 4 threads 2.4Ghz processor Max Turbo Frequency 3.0Ghz |
| CPU Package | BGA |
| Chipset | Intel® Broadwell-U series SOC |
| BIOS | EFI BIOS |
| RAM | Technology Architecture | Single Channel DDR3L 1066/1333/1600MHz |
| Capacity | Onboard 2GB4GB DDR3L |
| RAM Slot | 1x RAM slot ,max. 8GB RAM |
| VIDEO | Graphic Controller | Intel HD Graphics 5500(I3-5010U’s Graphics);Graphic core depends on CPU |
| Dual LVDS&EDP | Support dual channel 24bit output,max. Resolutions 1920 x 1200,EDP max. Resolutions 3840*2160(Optional) |
| VGA | VGA support max. Resolutions :2048x1536 |
| HDMI | HDMI(HDMI1.4)max.resolution :3200*2000@60HZ,Support 4K output |
| Dual display | LVDS + VGA,LVDS+HDMI,HDMI+VGA Synchronous or asynchronous display |
| Three Display | Support LVDS+VGA+HDMI Three-screen synchronous or asynchronous display |
| I/O Panel | Ports | 1*VGA,1*HDMI,1*LAN,2*USB3.0,2*USB2.0/1*MIC-OUT/LINE-OUT,1*SPDIF |
| NETWORK | CONTROLLER | 2*RTL8111E-V 1000M LAN,RJ45 port |
| Audio | CONTROLLER | REALTEK HD ALC662 Audio (MIC+SPK) |
| Super I/O | CONTROLLER | NCT6106D |
| HARDWARE MONITORING | Watchdog timer | 0-255sec, sample code optional |
| Cooler | Alluminum Alloy heat sink with Fan(Support automatic and manual fan speed adjustment) |
| Input/output interface | USB | 5*USB3.0 compatible USB2.0 / 1.1,10*USB2.0(When touch screen can use,only have 9*USB2.0,max. Support +5V/1.5A |
| Serial ports | 4*RS-232,2*RS422/485,RS485 Support automatic flow control(can choose as 6*RS232) |
| PS/2 | 1*PS/2 Pin Headers |
| Touch Panel | Support touch screen(4wire 5wire 8wire) |
| GPIO | 8bit,sample code, Free defination input or output ,3.3V@24mA |
| EXPANSION BUS | Mini-PCle | 1*Mini-PCIe slot,Support PCIe and USB device |
| STORAGE | SATA | 2*Standard SATA3.0 , 6GB/s maximum speed |
| Onboard SSD | Onboard SSD 16/32/64G(Optional) |
| M-SATA | 1*M-SATA Scoket,support SANDISK protocol , 6gb/s maximum |
| POWER SUPPLY | Power supply TYPE | Single DC input,DC12V,+/-5% |
| Power supply consumption | 35W |
| Work environment | Working temperature | -20°C~60°C (-32°F~140°F) |
| Storage temperature | -40°C~85°C (-104°F~185°F ) |
| Working humidity | 10%~90% (non-condensing) |
| Storage humidity | 10%~90% (non-condensing) |
| Measure | Size | 170mm x 170 mm |
| Weight | 0.5KG |
